| Type | Micro dc gear motor |
| Material | Stainless steel |
| Advantage | Small dimension,low noise, low price, long life, With High toruqe,Ce, CCC, Rohs |
| Application |
Scissors machine, crane machine, electric-drive toy, projector, intelligent robot, automatic valve, strongbox, dryer drying machine, automatic door-lock, intelligent cleaner,ATM bank automatic system, intelligent lock, lampblack machine, liquid crystal display screen, electric curtain, tie-yarn machine, massager, coffee machine, entertainment machine, automation Majang machine, automation machine, automation Majang machine, etc. |
| Motor |
Rated voltage |
No load speed |
No load current |
Rated speed |
Rated torque |
Rated current |
Output |
Stall torque |
Stall current |
| VDC | r/min | mA | r/min | g.cm | mA | W | g.cm | A | |
| DMK-555-1236 | 12 | 3600 | 150 | 3200 | 200 | 1000 | 5.7 | 1150 | 5.5 |
| DMK-555-1245 | 12 | 4500 | 200 | 4200 | 220 | 1100 | 6 | 1100 | 5 |
| DMK-555-2453 | 24 | 5300 | 120 | 5000 | 250 | 700 | 6.4 | 1000 | 2.7 |
Note: Above are only some typical models. For more information or a customized motor, Pls contact us.
Reduction Ratio:10-30
Reduction Ratio:44-90
Reduction Ratio:169-270
Reduction Ratio:506-810
