| Type | Micro dc gear motor |
| Material | Stainless steel |
| Advantage | Small dimension,low noise, low price, long life, With High toruqe,Ce, CCC, Rohs |
| Application |
Scissors machine, crane machine, electric-drive toy, projector, intelligent robot, automatic valve, strongbox, dryer drying machine, automatic door-lock, intelligent cleaner,ATM bank automatic system, intelligent lock, lampblack machine, liquid crystal display screen, electric curtain, tie-yarn machine, massager, coffee machine, entertainment machine, automation Majang machine, automation machine, automation Majang machine, etc. |
| MODEL | VOLTAGE | NO LOAD | AT MAXIMUM EFFICIENCY | STALL | |||||||
| SPEED | CURRENT | SPEED | CURRENT | TORQUE | OUTPUT | TORQUE | CURRENT | ||||
| v | r/min | A | r/min | A | mN.m | kg.cm | w | mN.m | kg.cm | A | |
| DK-32Z370-337 | 24 | 25 | 0.108 | 17 | 0.504 | 954 | 9.7 | 1.97 | 4520 | 46 | 1.5 |
| DK-32Z370-108 | 24 | 65 | 0.094 | 49 | 0.389 | 334 | 3.4 | 1.78 | 1590 | 15.6 | 1.2 |
Note: Above are only some typical models. For more information or a customized motor, Pls contact us.
| Gear length | Reduction Ratio | |||
| 22.6 | 52 | 65 | 108 | 135 |
| 270 | 337 | 621 | 810 | |
| 950 | 1012 | |||
