Motor Performance Parameters
| Type | Power W |
Voltage V |
No-load Parameters | Load Parameters | Brush Life H |
Motor Weight kg |
|||
| Speed | Current | Speed | Torque | Current | |||||
| r/min | A | r/min | mN.m | A | |||||
| Z5D | 40 | 12 | 3200 | 2.0max | 3000 | 127 | 5.2 | 2000 | 1.9 |
| 40 | 24 | 3000 | 1.0max | 2800 | 140 | 2.2 | 2000 | 1.9 | |
| 40 | 90 | 3100 | 0.3max | 2950 | 129 | 0.6 | 2000 | 1.98 | |
| 60 | 12 | 3200 | 2.0max | 2950 | 194 | 7.5 | 2000 | 2.2 | |
| 60 | 24 | 3100 | 1.5max | 2800 | 210 | 3.5 | 2000 | 2.2 | |
| 60 | 90 | 3200 | 0.3max | 3000 | 191 | 1.0 | 2000 | 2.2 | |
| 90 | 12 | 3300 | 3.0max | 2800 | 307 | 10.0 | 2000 | 2.2 | |
| 90 | 24 | 3100 | 1.5max | 2800 | 307 | 5.0 | 2000 | 2.2 | |
| 90 | 90 | 3100 | 0.5max | 2850 | 302 | 1.5 | 2000 | 2.2 | |
| 120 | 12 | 3400 | 3.0max | 3000 | 382 | 14.0 | 2000 | 2.2 | |
| 120 | 24 | 3100 | 1.5max | 2600 | 441 | 7.0 | 2000 | 2.2 | |
| 120 | 90 | 3300 | 0.3max | 3000 | 382 | 1.8 | 2000 | 2.2 | |
Note: Above are only some typical models. For more information or a customized motor, Pls contact us.
Gearbox model:5GN∏K
The max allowable torque of the gearbox: 10.0nm
Transmission efficiency:gear ratio:3-18:81%, 25-36:73%, 50-200:66%
Dimensions (Unit: mm )
40w
60W
90W
120W
