Motor Specification:
| Model | D5BLD750-24GU-30S | D5BLD750-36GU-30S | D5BLD750-48GU-30S | D5BLD750-310GU-30S |
| Power W | 750 | 750 | 750 | 750 |
| Voltage V | 24 | 36 | 48 | 310 |
| No load speed rpm | 3300 | 3300 | 3300 | 3300 |
| Rated speed rpm | 3000 | 3000 | 3000 | 3000 |
| Rated current A | 39.06 | 26.04 | 19.53 | 3.02 |
| Rated torque N.m | 2.39 | 2.39 | 2.39 | 2.39 |
| Peak torque N.m | 7.16 | 7.16 | 7.16 | 7.16 |
| No-load current A | <9.20A | <8.13A | <6.50A | <1.61A |
|
Recommended drive model |
BLD-4850 | BLD-4830 | BLD-750 | BLD-750A |
ALLOWABLE TORQUE BEING WITH GEARHEAD
| Gearhead type | Gearhead model | Gear ratio |
| Long life, low noise | 6GU□K | 3、5、7.5、10、12.5、15、18、20、25、30、36、40、50、60、75、90、100、150、180、200 |
□ 104# different specification based on different gear ratio:
Dimensions (Unit: mm )
Mounting screws are included with gearhead
Wire Definition:
| Power wire | Hall wire | ||||||
| Red | Yellow | Black | Red | Black | Hu | HV | HW |
| U | V | W | 5V | GND | Blue | Green | White |
