Motor Specification:
| Model |
D5BLD300-12A -20S |
D5BLD300-24A -20S |
D5BLD300-36A -20S |
D5BLD300-48A -20S |
D5BLD300-310A -20S |
| Power W | 300 | 300 | 300 | 300 | 300 |
| Voltage V | 12 | 24 | 36 | 48 | 310 |
| No load speed rpm | 2700 | 2700 | 2700 | 2700 | 2700 |
| Rated speed rpm | 2000 | 2000 | 2000 | 2000 | 2000 |
| Rated current A | 31.25 | 15.63 | 10.42 | 7.81 | 1.21 |
| Rated torque N.m | 1.43 | 1.43 | 1.43 | 1.43 | 1.43 |
| Peak torque N.m | 4.3 | 4.3 | 4.3 | 4.3 | 4.3 |
| No-load current A | <7.2A | <6.13A | <3.50A | <4.61A | <0.7A |
Available gear ratio for this kind of gear box
Please contact us for updated size drawing if you need different gear ratio:
